Pure SIP Recording

The world's first and only affordable SIP-compliant call recording system

In today’s global economy with ever-increasing pressure to compete and improve performance while maintaining compliance with stringent laws and regulations, call recording just makes sense. While large enterprises could generally afford the technologies to meet these needs, smaller organizations were shut out of the market.

Now every business can afford to record their mission-critical business calls with the industry’s most advanced yet affordable voice recording appliances for small and medium sized businesses. SIP Print delivers truly superior, full-featured, SIP-compliant recording appliances at a price that is a fraction of the cost of legacy analog recording systems. SIP Print’s appliances offer true system-level call recording for many of today’s leading VoIP phone systems.

SIP Print introduces an affordable IP-based network appliance that offers pure
system-level SIP voice recording for Small and Medium Businesses with 15-200
seats per location. And because it supports SIP at the communications system
level, SIP Print’s patent-pending platform can also record advanced functions
like voicemail or “follow-me” calls forwarded to mobile phones or off-premise
phone numbers.

Contact ABP to learn more about this incredible device.

Key Features
Technical Specifications
Downloads

Key Features

System

Web Based GUI
Remote Administration
Call Playback on Standard Media Players
Search by User Name
Extension & Name Lookup
Caller ID
Search by Area Code & Prefi x
Fast Forward & Rewind
Time and Date stamping
Email-ready Call File Formats
Multiple Manager Access
Remote Access
Easy Archive & Audit Trail
Column Sort (on the fly)

Compatibility

SIP
SIP Hybrid
MGCP
CALL CAPTURE
Trunk-side Analog CO, T1/PRI &

Trunking

Extension-to-Extension
Follow-Me Calls
User- and Extension-specific
SIP Registration
Captures SIP & RTP traffic

Voice Recording

Records one handset 24x7 for 2.5 years
Records all specified user calls on the
No logger patches
One appliance records all of your specified calls
No IP-PBX or handset integration

Technical Specifications

Software

Number of Users Supported: 15-200

Operating System: Proprietary O/S

Administrators: 1

Managers: 9

Total Concurrent Calls: 150Programming: GUI / DTMF

Media Players

WAV (.wav) media file

Web Browsers Supported: MS Internet Explorer, Mozilla Firefox, Apple Safari

Media Players Supported: MS Windows Media Player, Adobe Media Player, Apple Quicktime

System specifications

CPU Xeon 5100/5000 Dual Core Series Processor

Dual Port Ethernet/Fast Ethernet/Gigabit

Form Factor: 1U rack-mountable chassis

Dimensions: 17.2”W x 1.7”H x 14.5”D

Front Panel Power Button

Reset Button

Power LED

Hard Drive activity LED

Network activity LEDs

System overheat LED

110-250 Volt Auto Adjusting Power Supply

Hardware Specification

Operating Temperature: 0° to 50 °C (32° to 122 °F)

Storage Temperature: -20° to 70 °C (-4° to 158 °F)

Relative Humidity: Up to 75%, non-condensing

Downloads

SIP_DataSheet.pdf

How_It_Works.pdf

Administrator_Guide.pdf
