Aastra ViPr™ Multimedia Conferencing |
    |
 |
 |
 |
 |
 |
Technical Specifications
VMC 5000 Series
Bandwidth
• SIP support ranging from 128 Kbps to 3 Mbps
• H.32x support ranging from 128 Kbps to 2 Mbps
Avistar C3 Tunnel Server™
Video Standards: H.261, H.263, H.264 & MPEG-2 (decode only for compatibility with earlier ViPr™ systems)
Video Features:
• Individual placement of call participants to suit viewing
preferences
• 30 frames per second of 640x480 video resolution
• Enhanced conference modes to display video participants in
multiple views
• Concurrent “view call” windows and streaming video
• View collaboration on the ViPr™ screen while participating in
active calls
Video Inputs:
• Support for dual display with PC video pass-through
(VMC5400 only)
• S-Video
– Four S-Video inputs for VMC5400
• 1 extended graphics array (XGA) input (PC input); 1024x768,
60 Hz (VMC5400 only)
Video Format:
• National television standards committee (NTSC), phase
alternation line (PAL)
• Graphics: XGA
Frame Rates: 30 frames per second at 128 Kbps and above
Audio Standards: G.728, G.722.1, G722, G.721, G.711
Audio Features:
• Wideband audio
• Full-duplex audio
• Automatic gain control
• Microphone/speaker mute
• Individual and global volume controls to manage each
participant’s audio
Audio inputs/outputs
• 1 output for external speakers
• 1 analog input for PC audio
Network Interfaces: 10/100 (RJ-45)
Presentations and Collaborations: (Available with the VMC5400 only)
• Initiates a screen capture that can be shared with all members
of a call
• Initiates an associated Microsoft NetMeeting or Microsoft
Office Live Meeting session with a call party’s PC (requires the
ViPr™ PC application to be installed on your neighboring PC)
• Accesses your remote PC
Multi-site Features:
• On-demand conference capabilities
• No MCU required
• Conferences up to 100 participants
• Stereo audio allows for talk-over capabilities
Security Features:
• Secure end to end conferencing using AES-128 encryption
of all voice and video channels (VMC5400 with purchase of
additional AES license)
• Management via Hypertext Transfer Protocol over Secure
Socket Layer (HTTPS)
• Administrator passwords
• SIP Digest Authentication
• User authentication via ViPr™ database, Windows/server
message block (SMB) server, or Kerberos 5 server
• User authentication and access to contacts/settings
information is protected via Transport Layer Security (TLS)
System Management:
• End-point specific configuration
• Remote software upgrades
• Network statistics provided for troubleshooting
• Remote management via a Web interface on the ViPr™
Application Server
Directory Services:
• Personal and global user directories
• Interfaces with Lightweight Directory Address Protocol (LDAP)
for user directories
• 2,000-contact global directory
• Grouping capabilities within directories
Language Support: English, Japanese, Simplied Chinese
Customizable Messaging: pre- and post login banners
Dimensions (H x W x D): 3.5 in (8.89 cm) x 17 inc. (43.18 cm) x 14.375 in. (37.47 cm)
Environmental:
• Operating altitude 0 to 10,000 ft (0 to 3,048 m)
• Operating humidity 20% to 85%
• Operating temperature 32° F to 104° F (0° C to 40° C)
• Storage altitude 0 to 30,000 ft (0 to 9,144 m)
• Storage humidity 5% to 85%
• Storage temperature -40° F to +158° F (-40° C to +70° C)
Power:
• Auto-sensing power supply
• Cooling load (typical) 900 BTUs/hour
• Input (maximum) 120/220 VAC, 50/60 Hz, 5/2.5 A
Standards Compliance:
• U.S. CFR 47 Part 15, Class A (FCC); UL 60950, 3rd Edition
• Canada CAN/CSA 22.2 No. 60950-00, DOC Class A
• Europe/UK IEC 60950, 3rd Edition (1999); EN55024; EN55022,
Class A (CE)
• Japan VCCI, Class A
Weight: 19 lbs (8.62 kg)
VMC 6000 Series
Bandwidth:
• SIP support ranging from 128 Kbps to 3 Mbps
• H.32x support ranging from 128 Kbps to 2 Mbps
Video Standards:
• H.261, H.263, H.264 & MPEG-2 (decode only for compatibility
with earlier ViPr™ systems)
Video Features:
• Individual placement of call participants to suit viewing
preferences
• 30 frames per second of 640x480 video resolution
• Enhanced conference modes to display video participants in
multiple views
• Concurrent “view call” windows and streaming video
• View collaboration on the ViPr™ screen while participating in
active calls
• Support for dual display with PC video pass-through
(VMC6400 only)
Video Inputs:
• S-Video
– Four S-Video inputs for VMC6400
• 1 extended graphics array (XGA) input (PC input); 1024x768, 60
Hz (VMC6400 only)
Video Outputs:
• 1 wide extended graphics array (WXGA) output; 1280x768, 60
Hz (HD15)
• 1 extended graphics array (XGA) output; 1024x768,
60 Hz (HD15) (VMC6400 only)
Video Format:
• National television standards committee (NTSC), phase
alternation line (PAL)
• Graphics: XGA
Frame Rates: 30 frames per second at 128 Kbps and above
Audio Standards: G.728, G.722.1, G722, G.721, G.711
Audio Features:
• Wideband audio
• Full-duplex audio
• Automatic gain control
• Microphone/speaker mute
• Individual and global volume controls to manage each
participant’s audio
Audio Inputs/Outputs:
• 1 output for external speakers
• 1 analog input for PC audio
Network Interfaces: 10/100 (RJ-45)
Presentations and Collaborations:
(Available with the VMC6400 only)
• Doubles as your PC monitor or accesses your remote PC
• Initiates a screen capture that can be shared with all members
of a call
• Initiates an associated Microsoft NetMeeting or Microsoft
Office Live Meeting session with a call party’s PC (requires the
ViPr™ PC application to be installed on your neighboring PC)
Multi-site Features:
• On-demand conference capabilities
• No MCU required
• Conferences up to 100 participants
• Stereo audio allows for talk-over capabilities
Security Features:
• Secure end to end conferencing using AES-128 encryption
of all voice and video channels (VMC6400 with purchase of
additional AES license)
• Management via Hypertext Transfer Protocol over Secure
Socket Layer (HTTPS)
• Administrator passwords
• SIP Digest Authentication
• User authentication via ViPr™ database, Windows/server
message block (SMB) server, or Kerberos 5 server
• User authentication and access to contacts/settings
information is protected via Transport Layer Security (TLS)
System Management:
• End-point specific configuration
• Remote software upgrades
• Network statistics provided for troubleshooting
• Remote management via a Web interface on the ViPr™
Application Server
Directory Services:
• Personal and global user directories
• Interfaces with Lightweight Directory Address Protocol
(LDAP) for user directories
• 2,000-contact global directory
• Grouping capabilities within directories
Language Support: English, Japanese, Simplied Chinese
Customizable Messaging: Pre- and Post-login banners
Dimensions (H x W x D): 18.25 in. (46.36 cm) x 17.5 in. (44.45 cm) x 7.5 in. (19.05 cm)
Environmental:
• Operating altitude 0 to 10,000 ft (0 to 3,048 m)
• Operating humidity 20% to 85%
• Operating temperature 32° F to 104° F (0° C to 40° C)
• Storage altitude 0 to 30,000 ft (0 to 9,144 m)
• Storage humidity 5% to 85%
• Storage temperature -40° F to +158° F (-40° C to +70° C)
Power:
• Auto-sensing power supply
• Cooling load (typical) 900 BTUs/hour
• Input (maximum) 120/220 VAC, 50/60 Hz, 5/2.5 A
Standards Compliance:
• U.S. CFR 47 Part 15, Class A (FCC); UL 60950, 3rd Edition
• Canada CAN/CSA 22.2 No. 60950-00, DOC Class A
• Europe/UK IEC 60950, 3rd Edition (1999); EN55024; EN55022,
Class A (CE)
• Japan VCCI, Class A
Weight: 25 lbs (11.34 kg)
 |
 |
 |
 |
